I. Core Functions and Performance Advantages
Perkins piston ring KRPK0001 is a core component of the engine's four-match system. Through a triple sealing design (top ring, second ring, and oil ring), it effectively controls the upward movement of engine oil, reduces blue smoke emissions, and enhances combustion efficiency. The plasma molybdenum-based coating surface treatment is adopted, reducing the friction coefficient by 40% and enhancing the wear resistance by three times. It is suitable for extreme working conditions ranging from -30°C to 400°C, avoiding insufficient cylinder pressure and power attenuation caused by ring groove wear.
Ii. Innovation in Technical Specifications and Materials
Precision dimensions: Standard diameter 105mm (tolerance ±0.002mm), ring thickness 3.5mm+2.5mm+3.5mm combination, perfectly matching the original factory cylinder liner clearance.
Reinforced materials: The top ring is made of ductile iron and chromium ceramic composite layer, the second ring is conical nickel alloy, and the oil ring integrates a spring expansion ring structure to ensure elastic durability.
Durability test: After 200 hours of full-load bench test, the oil consumption rate is ≤0.15g/kWh, far exceeding the industry standard.
Iii. Compatible Models and Alternative Numbers
Replace the part number with the original factory engine model
Perkins 1104D-44 UPRK0002, T417956
Perkins 403D-07/15T CH12541, 4P-54448
Perkins 404D-22 CV66887/1
Application fields: Construction machinery (JCB excavators, Bobcat loaders), generator sets (Wilsun, Stamford), agricultural equipment.
Iv. Installation Guide and Fault Prevention
Key installation steps
Clean the inner wall of the cylinder liner and apply engine oil for lubrication.
Install with a dedicated expansion clamp, with the ring opening gap offset by 120°.
Check the side clearance (0.08-0.12mm) and back clearance (0.3-0.5mm). If they exceed the tolerance, the cylinder liner needs to be replaced.
Common Fault avoidance
Abnormal consumption of engine oil: It indicates insufficient tension of the oil ring or out-of-round cylinder liner. The wear of the ring groove needs to be checked.
Insufficient cylinder pressure: The top ring seal fails or gets stuck due to carbon deposits. It is recommended to clean the carbon slag in the ring groove regularly.
V. Genuine Product Procurement and Quality Assurance Services
Ningbo Qiuning Trading Co., Ltd. offers original factory-grade quality piston rings, supports warranty, and offers exclusive discounts for bulk purchases.
