The core advantage of Perkins regulator 185516061 lies in its instantaneous response technology, with a built-in high-sensitivity signal receiving module that can capture changes in equipment operating parameters within 0.1 seconds, adjust the output signal in real time, and ensure that the engine maintains a stable speed during load fluctuations, avoiding power fluctuations caused by regulation lag. It is particularly suitable for scenarios such as generator sets and precision engineering machinery that require high operational stability.
The regulator adopts a global adaptation design and is compatible with more than 20 engine models including Perkins 900 series, 1100 series, 1500 series, etc. through modular interfaces, including mainstream models such as 904D-27TG, 1106D-E66TA, 1506C-E88TAG, etc. No additional interface modification is required, simply connect to the original control system of the device, eliminating the need for complex parameter debugging and significantly reducing the difficulty of adaptation.
Anti interference performance is its prominent feature, and the internal circuit adopts a multi-layer shielding design, which can effectively resist interference signals such as electromagnetic radiation and voltage pulses. Tested to operate continuously for 500 hours in a strong electromagnetic environment, the adjustment accuracy remains within ± 2%, with no signal disorder or misoperation, ensuring stable operation in strong interference environments such as industrial plants and substations.
The material selected is a combination of high-temperature resistant engineering plastic and brass contacts. The shell can withstand extreme temperatures ranging from -40 ℃ to 85 ℃. The contacts have undergone 100000 on-off tests without oxidation, and can still maintain good conductivity and structural stability in humid and dusty outdoor conditions. The service life is extended by more than 30% compared to ordinary regulators.
|
4006 -23TAG3A
|
|
|
|
DGDF2378U14389S
|
|
|
|
Maintenance parts
|
|
|
|
ITEM
|
Part name
|
Part number
|
|
1
|
Fuel Filter
|
SE429B/4
|
|
2
|
Oil Filter
|
SE111B
|
|
3
|
Air Filter
|
S551/4
|
|
4
|
ALTERNATOR BELT
|
541/398
|
|
5
|
FAN BELT
|
541/439
|
|
|
|
|
|
minor repair
|
|
|
|
ITEM
|
Part name
|
Part number
|
|
1
|
SEAL - ROCKER BOX COVER
|
SE478F
|
|
2
|
GASKET - CYLINDER HEAD
|
SE2H
|
|
3
|
THERMOSTAT
|
SE573/1
|
|
4
|
FRONT OIL SEAL
|
554/126
|
|
5
|
SEAL - REAR END OIL
|
554/127
|
|
medium repair
|
|
|
|
ITEM
|
Part name
|
Part number
|
|
1
|
Fuel Filter
|
SE429B/4
|
|
2
|
Oil Filter
|
SE111B
|
|
3
|
ALTERNATOR BELT
|
541/398
|
|
4
|
FAN BELT
|
541/439
|
|
5
|
Air Filter
|
S551/4
|
|
6
|
SEAL - ROCKER BOX COVER
|
SE478F
|
|
7
|
GASKET - CYLINDER HEAD
|
SE2H
|
|
8
|
PISTON RING KIT
|
359/552
|
|
9
|
INTAKE AND EXHAUST VALVE
|
SE7AJ/14
|
|
10
|
INJECTOR
|
858/25
|
|
11
|
THERMOSTAT
|
SE573/1
|
|
12
|
TOP GASKET KIT
|
6SE663R
|
|
13
|
BOTTOM GASKET KIT
|
6SE663N
|
|
overhaul
|
|
|
|
ITEM
|
Part name
|
Part number
|
|
1
|
Fuel Filter
|
SE429B/4
|
|
2
|
Oil Filter
|
SE111B
|
|
3
|
FAN BELT
|
541/439
|
|
4
|
ALTERNATOR BELT
|
541/398
|
|
5
|
Air Filter
|
S551/4
|
|
6
|
THERMOSTAT
|
SE573/1
|
|
7
|
VALVE SEAT INSERT
|
740/101
|
|
8
|
VALVE SEAT INSERT
|
740/106
|
|
9
|
VALVE GUIDE
|
392/42
|
|
10
|
INTAKE AND EXHAUST VALVE
|
SE7AJ/14
|
|
11
|
VALVE COLLET
|
HW7B/18
|
|
12
|
VALVE SPRING
|
365/472
|
|
13
|
CAP
|
L7C/15
|
|
14
|
BIG END BEARING KIT
|
SE91AA/3M
|
|
15
|
PISTON AND RING KIT
|
SE901BA
|
|
16
|
CYLINDER LINER
|
SE7E/2
|
|
17
|
SEAL - O RING
|
576/167
|
|
18
|
MAIN BEARING KIT
|
SE574D/M
|
|
19
|
THRUST WASHER KIT
|
262/149
|
|
20
|
STARTER MOTOR
|
701/136
|
|
21
|
WATER PUMP
|
SE145AX
|
|
22
|
ALTERNATOR
|
702/186
|
|
23
|
INJECTOR
|
858/25
|
|
24
|
TURBOCHARGER
|
SE652CJ
|
|
25
|
GASKET - TURBOCHARGER
|
282/292
|
|
26
|
GASKET - CYLINDER HEAD
|
SE2H
|
|
27
|
SEAL - ROCKER BOX COVER
|
SE478F
|
|
28
|
FRONT OIL SEAL
|
554/126
|
|
29
|
SEAL - REAR END OIL
|
554/127
|
|
30
|
SEAL - SUMP
|
6SE70C
|
|
31
|
PRIMING PUMP
|
879/39
|
|
32
|
OIL PUMP
|
SE116AC
|
|
33
|
PRESSURE SWITCH
|
782/175
|
|
34
|
SPEED SENSOR
|
838/14
|
|
35
|
SPEED SENSOR
|
680/124
|
|
36
|
CRANKSHAFT ASSEMBLY
|
6SE92Q
|
|
37
|
CAMSHAFT
|
6SE100AD
|
